Product Focus: Single-Jet, Vane Wheel, Dry-Dial Water Meter

I. Product Overview

Our single-jet dry-dial water meter is a velocity-type meter designed for accurate measurement of potable water consumption in residential and light commercial applications. Featuring a single-nozzle impingement design, magnetic drive transmission, and a vacuum-sealed dry register, this meter offers reliable performance, clear long-term readability, and resistance to external magnetic interference.

II. Operating Principle

Water enters the meter body through the inlet and passes through a single jet nozzle, which directs a concentrated stream against the vane wheel at the tip of its blades. The impact of the water jet causes the vane wheel to rotate at a speed directly proportional to the water flow velocity. This rotation is transmitted magnetically—through a magnetic coupling—to the sealed register, where the totalized volume of water passing through the meter is displayed and recorded. The dry-dial design ensures that the counting mechanism is completely isolated from the water, preventing fogging and keeping the reading clear over the long term.

III. Product Features

Single-Jet Design: Uses a single input port to create a focused jet of water against the impeller, providing accurate measurement in smaller pipe sizes commonly used in residential settings.

Dry-Dial Register: The counting mechanism is vacuum-sealed and physically separated from the water flow. This prevents condensation and fogging, ensuring the dial remains clear and readable throughout the meter's service life.

Magnetic Drive: The rotation of the vane wheel is transmitted to the register via a magnetic coupling, eliminating the need for mechanical feed-throughs that can wear or leak.

Anti-Magnetic Protection: Designed to resist interference from external magnetic fields, preventing tampering or inaccurate readings.

Durable Construction: Available in both brass and plastic body options to suit different application requirements and budgets. An internal strainer element protects the vane wheel from debris and clogging, ensuring long-term reliability.

IV. Quality and Standards

The meters are manufactured in compliance with ISO 4064 and GB/T778.1 international standards. Quality control processes include incoming material inspection, in-process random checks, and full inspection of finished goods to ensure consistent accuracy and reliability.

V. Cooperation Models

Product Selection: Direct ordering from existing model catalog

Custom Sampling: Custom production based on client specifications

OEM Manufacturing: Production and packaging according to client brand requirements

Our single-jet dry-dial water meters have been consistently supplied to domestic and international utility companies, waterworks, and distributors. For product catalogs, samples, or inquiries, please contact our sales department.
